Paper Covered Aluminum Wire
Last Updated ：2023/07/03
Paper covered insulated aluminium wire
Telephone cable paper/3M paper/MIKITOKU paper covered insulated aluminum wire
Description of Paper Covered Aluminum Wire
These Paper Covered Aluminum Wires and Strips are made from very high quality raw material which ensures hassle free work performance at its user end. These Paper Covered Aluminum Wires and Strips are technologically advanced and confirm to industrial quality norms of international standard. These Paper Covered Aluminum Wires and Strips are widely finds its applications in various industrial sectors.
 |
 |
Production Range :
1.Paper covered Flat Aluminum wire
Thickness: 1mm--7mm
Width: 3.0--20mm
2.Paper covered Round Aluminum wire
Diameter: 1.9mm--10.0mm
If required special size, please contact us.
Standard : IEC,NEMA,GB, JIS
Package : 30kg/50kg/150kg wooden spool or according to customers requirements
Typical Applications : Oil-filled transformers ; Utility transformers ; Power generators ;
We apply following basic types of insulation on Aluminium :
* Electric Grade Insulating Kraft Paper
* Super Combed cotton Yarn
* Nomax Type
Product Name and Type
| Product Name | Type | Product Name | Type |
| Paper covered round copper wire strip | Z | Paper covered flat copper wire strip | ZB |
| Paper covered round aluminum wire strip | ZL | Paper covered flat aluminum wire strip | ZLB |
|
500KV transformer interturn insulation paper covered round copper wire |
ZA |
500KV transformer interturn insulation paper covered flat copper wire |
ZAB |
|
500KV transformer interturn insulation paper covered round aluminum wire strip |
ZAL |
500KV transformer interturn insulation paper covered flat aluminum wire strip |
ZALB |
Standard:
| Project Name | Standard | Test tool | |||||||||||
| Conductor size and R corner radius | Follow standard of GB/T7673.1-87 | Micrometer and R type | |||||||||||
| Bend |
The specimen is not cracked, no crack, no obvious sticking out of the paper, according to the standard curve. |
Experimental round rod and flat wire bending apparatus |
|||||||||||
| Paper Covered Round Wire Insulation Thickness | |||||||||||||
| Standard Insulation Thickness(mm) | 0.3 | 0.45 | 0.80 | 1.20 | 1.80 | 4.25 | |||||||
| Tolerance(mm) | ±0.05 | ±0.05 | ±0.10 | ±0.12 | ±0.15 | ±0.30 | |||||||
| Paper Covered Flat Wire Insulation Thickness | |||||||||||||
| Standard Insulation Thickness(mm) | 0.45 | 0.60 | 0.95 | 1.35 | 1.60 | 1.95 | 2.45 | 2.95 | |||||
| Maximum Insulation Thickness(A-a) | 0.57 | 0.74 | 1.14 | 1.56 | 1.84 | 2.23 | 2.77 | 3.32 | |||||
| Minimum Insulation Thickness(B-b) | 0.40 | 0.53 | 0.85 | 1.20 | 1.45 | 1.80 | 2.30 | 2.75 | |||||
Quality:
We manufacture according to the quality assurance standards of BIS and IES. We are equipped with total set of in house testing facilities to meet the requirement of standered in order to defect free products.
Our Target:
To provide Qualitative products at competitive price with prompt delivery.
We have been successful in leading the market by manufacturing and supplying an affordable range of Paper Covered Aluminium Wire. These wire reels are manufactured using highest quality aluminium that is procured from the authorized vendors of the market. By keeping in mind the industrial norms and standards, these wires are widely acclaimed among our clients for their high performance and durability. Paper Covered Aluminium Wire are rolled and packed with premium packaging before being supplied to the customer.
